KARCHER HD5/13 CLASSIC HIGH PRESSURE WASHER *KAP | 1.520-022.0
|
KARCHER HD5/13 CLASSIC HIGH PRESSURE WASHER *KAP | 1.520-022.0Weight: 40 kg
63 cm (L) x 43 cm (W) x 95 cm (H)
RM 2,699.00
1 In Stock
Quantity
|
Ergonomic, portable, powerful and durable: the classic range impresses with its durable and reliable components,
such as hard-wearing crankshaft pumps and induction motors, as well as its sophisticated design,
which is developed for low to medium-intensity use. Not only do the crankshaft pumps with brass cylinder
heads offer outstanding performance and durability from superior sealing technology, but they are also very easy to maintain.
The machines feature an ergonomic handle, large wheels and high-quality castor with parking brake for extra convenience
during operations that require frequent changes of position. Thanks to its high working pressure and water flow rate,
it is the ideal choice for car workshops, vehicle rental stores, car wash centers or tunnels, building service contractors,
trade professionals, small construction companies, small garages and farms and for diverse applications,
such as car washing or routine cleaning of paving, walls and glass, etc. With the patented Kärcher power nozzle,
it can deliver up to 40 per cent more impact force than conventional nozzles for thorough cleaning results.
FEATURES AND BENEFITS
Durable and robust
Large crankshafts and connecting rods with robust ball bearings.
High-quality brass cylinder head and high-performance sealing packages for longer working times.
Powerful, air-cooled electric motor.
Very easy servicing
Cylinder head is accessed quickly, simply by removing the machine cover.
Easy-to-access water filter protects the pump against dirt particles in the water.
Excellent portability
The robust D250 wheels are ideal for tough applications.
The high-quality castor with parking brake is ultra-convenient for operations that require frequent changes of position.
Features an ergonomic handle for easy carrying, even over long distances.
Increased energy efficiency
Newly developed crankshaft pump with reduced flow and pressure loss.
Patented Kärcher power nozzle can offer up to 40 per cent more impact force than conventional nozzles.
SPECIFICATIONS
Technical data
Supply voltage (V/Hz) 220 / 50
Flow rate (l/h) 500
Inlet temperature (°C) 60
Working pressure (bar) 130 - max. 170
Max. pressure (bar) 170
Power cable (m) 5
Weight (with accessories) (kg) 37.4
Weight incl. packaging (kg) 39.9
Dimensions (L x W x H) (mm) 636 x 438 x 957
APPLICATION AREAS
- Ideal for car workshops, vehicle rental stores, car wash centers, building service contractors, trade professionals, small construction companies, small garages and farms, etc.
- Also suitable for craft and construction companies or in building cleaning
GENERAL TERMS & CONDITIONS OF WARRANTY SOLD IN MALAYSIA
1. 1 (One) years warranty (Commercial)
2. The warranty terms published by the relevant sales company are applicable in each country.
3. This warranty shall be applicable for Product purchased and operated in Malaysia only.
If the product is shipped and operated outside Malaysia, the warranty becomes void.
4. Please submit the proof of purchase (e.g. relevant receipt/tax invoice) and/or warranty card
to customer service personnel. In case of loss of proof of purchase / purchased date is not
show on the relevant proof of purchase, we reserve right to use manufacturing date
(i.e. the serial no.) of the product as purchased date
5. Upon received the warranty claim, Karcher or its Authorized Service Centre shall at its discretion
to determine whether to repair or to make direct replacement of the product.
6. For High Pressure Cleaners, the warranty covers the replacement of Motor (Max 1 time)
and Pump (Max 2 times) within 2 years Warranty Period.
7. The undertaking and/or completion of repair, service or replacement of Product or its parts
shall in no circumstances extend the warranty period of the Product and it shall thereafter
continue to apply only for the remaining warranty period of the product.
8. For all warranty claims which require repair/service, it must be delivered/sent to/collected
from our customer service center at your own cost.
EXCLUSION OF WARRANTY
The Warranty does not cover the following:
1. Machine Damaged caused by
- Natural Disasters (Flood, Landslide, Wildfires etc).
- Misuse, abuse, or neglects of the machine.
-
Commercial use (multi-user organisations), public rental, use for profit, communal use for multi-family
housing areas, hotel/hostel, restaurant/laundry shop. - Improper storage of the machine.
- Unauthorized modification/repairs.
- Use of non-approved accessories/replacement parts.
- Failure to follow the product's operating & maintenance instructions.
- Accidentals & transportations/courier's damages.
- Wrongly installation process, modifications/mishandling.
- Low/high voltage, the use of an incorrectly sized extension leads/a coiled electrical extension lead.
- impurities in the water supply to the product and/or debris found contaminating the pump and motor.
- Usage of Non-Approved Chemicals.
2. Wear and tear parts (filters, brushes, high pressure hose / any other hoses, seals, o-rings, batteries, cloth sets, etc.
3. The product was purchased from outside Malaysia / Brunei.
